CH2O Sensor

Electrochemical Formaldehyde Module TE08-CH2O

To detect the CH2O

Application:

Portable instruments
air quality monitoring equipment
air purifiers
fresh air ventilation systems
air conditioners
smart home devices

Product characteristics:

High sensitivity, high resolution, low power consumption, long service life
Provide UART, analog voltage signal and other output modes
High stability, excellent anti-interference ability

Description


    TE08-CH2O electrochemical formaldehyde module is a universal, miniaturized module. It uses electrochemical principles to detect CH2O in the air, with good selectivity and stability. Built-in temperature sensor for temperature compensation; digital output and analog voltage output for easy use. TE08-CH2O is a universal gas module designed and manufactured by combining mature electrochemical detection technology with sophisticated circuit design.


Technical specifications


Product modelTE08-CH2O
Detection gasCH2O
Interfering gasAlcohol
Output dataDAC(0.4~2V Voltage signal
corresponds to concentration: 0~Full scale)
UART Output(3V TTL Level)
Operating voltage3.7V~5.5V
Warm-up time≤3 minutes
Response time≤60S
Recovery time≤60S
Range0~5ppm
Resolution≤0.01ppm
Operating temperature -20~50℃
Operating humidity 15%~90% RH(No condensation)
Storage temperature 0~25℃
Using life5 years(in air: 18℃~25℃)


Basic circuit


TenSensor, China's first listed gas sensor company,Tensensor can provide more than 100 varieties of six series including:

semiconductor gas sensor

electrochemical gas sensor

infrared gas sensor

dust sensor

pyroelectric sensor

thermopile sensor, etc.

which can be used for more than 200 kinds of gas and infrared, dust and other indicators detection, widely used in the field of security for  detecting gas leakage, noxious gas leakage, smog and fire, the field of family, office and factory for detecting HCHO, VOC, CO2, PM2.5 and so on.

Moreover, the solutions for security, household electrical appliances, consumer electronics, smart home, instruments and meters are available.

For more information about TE08-CH2O sensor, please contact  account manager.
